DRAWWORKS
Spencer Harris 7000 Powered by Two (2) 3406 CAT Diesel Engines
Foster Make-up and Break-out Catheads
Hydromatic Brake
SUBSTRUCTURE & DERRICK
Spencer Harris 9' Box-on-Box Type with Backup Ramp
Spencer Harris 96' High 250,000# SHL Hydraulically Raised and Mechanically Scoped Mast
MUD PUMPS
Gardner Denver FXN
Continental Emsco DB-550 Duplex Pump Powered by Detroit 12VN71 with Hydril
Pulsation Dampner Matco Forged Steel Fluid End
DRILL STRING
Drill Pipe- 11,000' 4" 14# Grade E and S with Full-Hole Connections
Drill Collars- Ten 6-1/4" Full-Hole Connections
GENERATOR/ WATER TANK
Delco 200 KW Generator Powered by 375 CAT Diesel Engine
CAT SR-4B 250 KW Generator Powered by 343 CAT Diesel Engine
MUD TANK SYSTEM
Two 300 Barrel Mud Tanks, 40' L x 10'W x 4'H with 10 HP Mud Agitators
SWACO Double Screen Shale Shaker
SWACO Desiliter
DEMCO Desander
Four (4) Mission Magnum 5" x 6" Centrifugal Pumps Powered by 50 HP Electric Motors 400
WELL CONTROL EQUIPMENT
Reagan 11" 3000 Annular BOP
5000# Choke Manifold with 4-Way Cross
|
ROTATING/TRAVELING EQUIPMENT
Oil Well 17.5 Rotary Table
Skytop Brewster 4SX Swivel
4-1/2" Square Kelly with HD Drive Bushing
Traveling Block with 150-Ton Hook
DOGHOUSE/FUEL TANK/CATWALK
8' Wide x 40' Long Top Doghouse w/20 Lockers and Knowledge Box
10' Wide x 8' High x 30' Long Fuel Tank with 4 Compartment Lubester
4' Wide x 60' Long Catwalk with Collar Box
HANDLING TOOLS/AUXILLARY EQUIPMENT
Electric Wire Line Device
BJ Type C Tongs
Drill Pipe Slips
BAASH-ROSS Drill Collar Slips, Elevator Links & Miscellaneous Handling Tools
Martin Decker Totco Weight Indicator
4" ID Rotary Hose
8-5/8" Casing Elevators
Three (3) Sets of Pipe Racks
LIVING QUARTERS
Fully Furnished Skid-Mounted Crew House with 10 Bunks
|
