DRAWWORKS
Sky Top Brewster - N46 Drawworks Powered by Two (2) GM Silver 8V-92T Diesel Engines
Foster Make-up and Break-out Catheads
Parmac V-80 Brake
SUBSTRUCTURE & DERRICK
Lee C. Moore 8' Box on 4' Pony Box
Lee C. Moore 136' High 595,000# Cantilever Mast
MUD PUMPS
Oilwell A1100 PT Triplex Pump with Pulsation Dampner, 50 HP Charge Pump, Matco Forged Steel Fluid End Powered by CAT 399 Diesel Engine
Oilwell A850 PT Triplex Pump with C-E Pulsation Dampner, 50HP Charge Pump, Matco Forged Steel Fluid End Powered by CAT 398 Diesel Engine
DRILL STRING
Drill Pipe - 14,000' 4-1/2" 20.00# and 16.60# Grades G, X, and E with X-Hole Connections
Dril Collars - Twenty 6-1/4" X-Hole Connections
GENERATOR/ WATER TANK
1997 CAT SR-4B 275 KW Generator, Serial # 9CR00919
Powered by CAT 3406, Serial # JLS00394
Delco 135 KW Generator Powered by GM 6-71 Diesel Engine
10' W x 8' H x 36'L Water Tank (500 Barrels) with 20' Long Generator Hose
MUD TANK SYSTEM
Three (3) 8'W x 5'H x 40'L Mud Tanks with Round Bottoms, Top & Side Mounted Walkways
Brandt Double Screen Shale Shaker
SWACO Desilter
DEMCO Desander
Three (3) Mission Magnum 5" x 6" Centrifugal Pumps Powered By 40 HP Electric Motors Sidewinder Mud Hopper
|
WELL CONTROL EQUIPMENT
Hydrill GK-11 5000# Annular BOP
Hydrill Type V 11 5000# Double BOP
5000# Choke Manifold with 4-Way Cross, WKM 4" 5000# w/(5) Cameron 2-1/16" 5000# Gate Valves
Valvcon 90-1K50-E10GDU2RH-4-1 4-Station 90-Gallon Closet Unit
Gardner Denver Triplex Charging Pump Powered by 5HP Electric Motor
GRACO Air Actuated Charging Pump 4' x 15' Gas Buster
ROTATING/TRAVELING EQUIPMENT
Oil Well A-20.5 Rotary Table
Two (2) Oil Well PC-225 Swivels
5-1/4" Hex Kelly with HD Drive Bushing
Continental Emsco RA-250 5-Sheave Block with Bj Dynaplex 250-Ton Hook
DOGHOUSE/FUEL TANK/CATWALK
10' Wide x 40' Long Top Doghouse w/20 Lockers and Knowledge Box
10' Wide x 8' High x 30' Long Fuel Tank with 4 Compartment Lubester
6' Wide x 40' Long Catwalk with Collar Box
HANDLING TOOLS/AUXILLARY EQUIPMENT
Mathey RET Hydraulic/Electric Wireline Device
Woolley Type B Tongs
Two (2) Sets of Drill Pipe Slips
BAASH-ROSS Drill Collar Slips, Elevator Links & Miscellaneous Handling Tools
Martin Decker Totco Weight Indicator
4" ID Rotary Hose
Four (4) Sets of Pipe Racks
LIVING QUARTERS
Fully Furnished Skid-Mounted Crew House with 12 Bunks
|
